Product Name:

    Markem Imaje 5800 Series


  • Print densities available: 1 to 8
  • Encoder scaling: Allows for conveyor line speed matching and for higher print speeds with a reduction in print resolution.
  • Print area: Maximum/printhead print height: 65 mm Print length: 1,000 mm
  • Print specification: Full true type font supported
  • Printing of real-time clock (hr/min), dates and auto updating best before dates and serial numbers.
  • Barcodes (Linear and 2D): ITF, Code 39, Code 128, EAN 128, EAN 8, EAN 13, UPC A, UPC E, Data matrix, RSS linear, RSS composite, QR, RSS 14, RSS expanded, PDF 417 *Maximum speed is application dependent.
  • Operations

  • 5800: Up to two print heads
  • User interface: Color LCD touch screen used for image selection, variable data entry, diagnostics and system setup.
  • Selectable multi-language menus
  • Image preview
  • Access level password protection
  • Full system diagnostic menu
  • Printhead orientations: Vertical or up to 20º of process direction
